Cyflwyniad Sihui Fuji PCBA
Gadewch neges
Mae Sihui Fuji yn wneuthurwr electronig sy'n targedu lefelau ansawdd o'r radd flaenaf.Gallwn ddarparu ateb un-stop cyflawn o ddylunio PCB ~ PCB ~ gweithgynhyrchu PCBA. Dibynadwyedd uchel, ansawdd uchel, ac amser dosbarthu byr yw'r hyn yr ydym yn ymdrechu i'w wneud.
Cynllun Planhigion
Gallu Cynhyrchu UDRh
|
Llinell |
Offer |
Rhannau lleiaf |
Gallu UDRh /H |
Capasiti llinell/M |
|
Llinell 1 |
KE2060M |
0402 |
|
|
|
Llinell 2 |
RX-8 |
0201 |
100,000 |
57,200,000 |
|
|
RS-1R |
0201 |
47,000 |
26,884,000 |
|
|
RS-1R |
0201 |
47,000 |
26,884,000 |
|
Llinell 3 |
RS-1R |
0201 |
47,000 |
26,884,000 |
|
|
RS-1R |
0201 |
47,000 |
26,884,000 |
|
|
RS-1R |
0201 |
47,000 |
26,884,000 |
|
Llinell 4 |
RX-8 |
0201 |
100,000 |
57,200,000 |
|
|
RS1-XL |
0201 |
47,000 |
26,884,000 |
|
|
RS1-XL |
0201 |
47,000 |
26,884,000 |
|
Cyfanswm capasiti:300 miliwn o bwyntiau / Mis |
||||
|
Llinell |
Proses |
Brand |
Model |
Gallu peirianneg |
Isafswm PCB (L*W) |
Uchafswm PCB (L*W) |
|
|
Llinell 4 |
Marcio laser |
Ruiitian |
RTM-C450 |
marc laser |
±0.02um |
50x50mm |
450x450mm |
|
|
Argraffu |
GKG |
GKG-GLS |
argraffu |
±12wm/±6σ |
50x50mm |
870x610mm |
|
|
SPI |
Sinig - Tek |
S8080L |
penderfyniad |
13wm |
50x50mm |
630x550mm |
|
|
3 set UDRh |
JUKI |
RX-8 / RS-1RS /RS1-XL |
Cywirdeb echel X/Y |
±35um |
50x50mm |
950x370mm |
|
|
AOI cyn reflow |
Sinig - Tek |
S510D |
penderfyniad |
10wm |
50x50mm |
550x450mm |
|
|
N2 reflow |
Jingtuo |
JTR-1003N |
Parth tymheredd |
10 |
W: 50mm |
W: 450mm |
|
|
AOI ar ôl reflow |
Sinig - Tek |
S510D |
penderfyniad |
10wm |
50x50mm |
550x450mm |
Cynllun a chynhwysedd RhYC
1, Ton sodro: 3 llinell gyda 4 parth Up-Down preheat a dyfais N2, mae ansawdd sodro a dibynadwyedd yn rhagorol.
2, Sodro dethol: 1 llinell gyda manwl gywirdeb uchel, dibynadwyedd uchel a cholled sodr fach.
|
Llinell |
Proses |
Brand |
Model |
Cynheswch |
Lled PCB Max |
Bar sodr |
Cynhwysedd (㎡) |
|
DIP #1 |
ton |
Ridong |
PEAK{0}} |
4 parth 2 ochr |
450mm |
ACA305 |
10,000 |
|
DIP #2 |
ton |
Jingtuo |
SMART-450-H |
4 parth 2 ochr |
450mm |
ACA305 |
10,000 |
|
DIP #3 |
ton |
Jingtuo |
SMART-350-H |
4 parth 2 ochr |
350mm |
ACA305 |
8,000 |
|
DIP #4 |
ton |
Jingtuo |
SMART-610-H |
4 parth 2 ochr |
540mm |
ACA305 |
15,000 |
|
DIP #5 |
dethol |
Xinrui |
SW-300S |
Maint lleiaf 50x50mm |
Maint mwyaf 300x250 |
ACA305 |
1,000 |
Offer Cynhyrchu
gosodwr JUKI RS-1R
Marciwr laser
Argraffydd past solder
rac casglu
Mesurydd clyfar FA
Pelydr-X pŵer uchel
Llywio modurol
Bwrdd rheoli A/C modurol
